Heinelec Combination RCD Circuit Breaker RCBO 1P+ N 20 Amp 110 to 240V AC 6 kA 3Module 78mm Clip Tray Surface

Description

Combination RCD Circuit Breaker RCBO, 20 Amp, 110 to 240 Volt AC, 50/60 Hz, Interrupt Capacity: 6 kA, Trip Sensitivity: 30 mA, Number of Poles: 1P + N, Number of Modules: 3, 78mm Module Width, 0.75 to 35 mm Terminal Connection, Shrouded Line and Load, IP2X, Clip Tray, Surface,-40 to 85 deg C, 119.5mm Height, 64.6mm Width, 80mm Depth

Key Specifications

Barcode (EAN-13)	9323952158898
SKU	HEISF15AE20
Brand	Heinelec
Range Name	SF15AE
Product Type	Combination RCBO

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Hydraulic-magnetic technology Immune to pulsating DC load current Single pole plus switched netural earth leakage protection Precision tripping characteristics Reset immediately after overload Suitable to use for electrical isolation
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	SF15AE20
Depth	80 mm
Connection Type	Shrouded Line and Load
Height	119.5 mm
Current	20 Amp
Frequency	50/60 Hz
Interrupt Capacity	6 kA
IP Rating	IP2X
Modules	3 Module 78 mm
Mounting Method	Clip Tray/Surface
Number Of Poles	1 Pole
Temperature	-40 to 85 deg C
Terminal Connection	0.75-35 sq-mm
Trip Sensitivity	30 mA
Voltage	110-240 Volt
Width	64.6 mm
